Electromagnetic Modelling of Power Electronic Converters

The era of the personal computer has, without doubt, permanently altered our life style in a myriad of ways. The "brain" of the personal computer is the microprocessor (together with RAM and ROM) which makes the decisions needed for the computer to perform in the desired manner. The microprocessor continues to evolve as increasingly complex tasks are required. While not sharing the limelight of the microprocessor, the "heart" of the personal computer, namely the power supply, is equally important since without the necessary source of power the microprocessor would be a useless piece of silicon. The power supply of twenty years ago was much different than its modem day equivalent. At the dawn of the personal computer era in the late 1970s, de power was obtained from a simple diode bridge. However, the need for smooth, regulated DC at low voltage required at the same time both a bulky input transformer and a large dc side ftlter. Those computer fans present at the birth of this industry can remember the large boxes housing our Altair, Cromemco and Northstar computers which was made necessary largely because of the huge power supply. It is not well appreciated but certainly true that the huge sucess of the Apple II computer in those days was due, at least in part, to the relatively slim proftle of the machine. This sleek appearance was largely due to the adoption of the then new and unproven switched mode power supply.

Inhalt

1 Circuit Analysis from an Electromagnetic Viewpoint; Design Optimisation beyond the Scope of Conventional Circuit Analysis Techniques.- 2 Poynting Vector, a Method to Describe the Mechanism of Power Conditioning.- 3 Power Conditioning in Electronic Circuits.- 4 Eddy Currents in Conductors.- 5 Structural Impedances of Power Connections; Analysis and Method of Calculation.- 6 Skin and Proximity Effect Losses in Transformer and Inductor Windings.- 7 Magnetic Field Inside Windings; a Key Parameter in the Proximity Effect Equation.- 8 Experimental Measurement of Eddy Current Losses in Transformer Windings and Inductor Coils.- 9 Evaluation and Conclusions.- A Experiment for Determining the AC Resistance of Inductor Coils and Transformer Windings.- B Computer Program PIP (Parasitic Impedance Program).- C Computer Program TID (Transformer and Inductor Design).- D Computer Program CID (Coil Inductor Design).- List of Symbols.
